Some kitchen uses such high power that a private group is needed. A well-known example is an electric stove. But there are more devices that belong to their group. Other devices can be safely combined. It is important there to have a good idea of when you place a new kitchen.
To determine what requirements your new kitchen sets to your electrical system, you should know what you want to put equipment in your kitchen. Kitchens are several devices that use high power and therefore can not collectively in one group. We put the most commonly used devices for you here. In general, it is the norm that a device on a private group with a connection value of more than 2000 watts belongs.
When the hob depends on it, what kind of stove you take. You cook on gas. The cooker is not relevant to your electrical installation. You will, of course, need to have close to the spot where does your cooker a gas connection. And possibly an electrical outlet, because of the ignition. If your stove does not need it, then prudent yet to make a connection. The stove keeps it probably shorter than the full kitchen. Should you replace the cooker, it is convenient that you’re prepared.
Cook on electric
Electric cooking (induction, electric, halogen and ceramic) almost always means that you need a three-phase connection. This is because of a cooker if you use all zones, uses more power than a single group can deliver. Sorry, you can not just use two groups when the two groups on the same stage. The main fuse of the stage for this fact too light. With a three-phase connection, you have that problem. You use two groups and thus divided the assets over several phases.
Electric cooking on a single?
There are plates which you can connect to a single group. This saves the need for a three-phase connection. That sounds great, but in practice is something else. The hob sees to it that never gets used too much power. That means you can not use all cooking zones simultaneously at maximum power. The hob will distribute the assets of the cooking zones used and do not exceed the maximum. To what extent in practice for you is a problem, you will have to decide.
Oven, microwave, or both
A furnace has long been a standard part of the kitchen. Which has long been fired by gas? But today is a normal electric oven. An oven is a device that uses a considerable power. The exact capacity varies by model. There is furnace with a connected load of 3,500 watts, which only belong to their group. There are also ovens, which have the half or even less power. There you need to have any special group, but you have to be careful that you are not too many other devices connected to the same group.
In addition to the oven, the microwave is also a popular device in many kitchens. Instead of a solo microwave, you can also go for a microwave oven. What you take, the same applies as for the oven. Some devices need their group, and others have such low power that there is still capacity of the group left for other things.
The dishwasher is another device that has become very popular in recent years. In a new kitchen includes a dishwasher at home, unless you do not have space for. A dishwasher heats, pumps and moving parts. This will also consume the energy. Regarding connectivity, the value is most dishwashers between 2000 and 2500 watts. That ability is so high that you have no other heavy loads to you close.
Water Boiler or Quooker
The boiling water tap or Quooker is one of the latest new developments in the kitchen. But because this device must keep the water at a high temperature, it is sometimes used the necessary electricity. The same is true for the regular water boilers which are to be found in some kitchen. In both devices, there is a heating element with a power of about 2000 to 2500 watts. Just as with the dishwasher these devices can not be in the same group as the other above-mentioned large-scale users.
Then there are also devices that do not have such high capabilities. Think of a refrigerator and freezer. These devices can be divided among the groups that you already need for your kitchen. You’ll have to count it, to see if you do not connect too much with a single group. On a group of 3,000 watts or more you better nothing. Please refer to the capabilities that use these devices. Usually, these devices are at around 150-300 watts.
Loose equipment, and electrical outlets
Separate devices plugged into an electrical outlet above your worksheet. Devices such as a kettle, coffee machine, best Masticating Juicer, and fryer are seen as small kitchen appliances but still, have considerable powers. Sometimes up to 2000 watts or more. Therefore, it is not wise to put your loose sockets in a group in combination with a device with a high power, such as a dishwasher, oven and the like. The last thing you want is to have to stop you simultaneously use certain devices. Otherwise, there goes a fuse.
Example of distribution groups
Every kitchen is unique, but regarding the kitchen is often the same. The consumed power do vary by model device, but in general, you do take an average. This can be used as a guideline. What you just need to check is whether you can not take much more powerful devices than the values set here. If not, then you can assume the following.
The table above is a good starting point. Especially when you still have to work because you do not meet current installation, it is advisable not to skimp on a group of more or less. An additional group is never in the way, but a group can be very annoying enough. The work and costs required to work on your system and kitchen will not rise much if you decide to use one or two additional groups. Let it work in your cupboard always do by someone with knowledge.
